AEM-1080Q
Fully Automatic Die Cutting
AEM 1080Q Fully Automatic Die Cutting Machine With Waste Clearance
- Perfect design, fine assemble, good stability, strong security, low noise.
- Worm, worm-gear, crankshaft transmission technology, high cutting pressure and long durability.
- High precision intermittent motion mechanism to make high precision die cutting and runs stably.
- Feeding parts from European technology, adjustable, stable, accurate and wide application for feeding.
- Feeding and delivery at working time to increase work efficiency.
- Die cutting plate and base plate mechanism, humanization design, fast and easy to install and change.
- Air locked plate to make more solidly and accurately, also save the time.
- Micro setting device of front gauge, size gauge, feeding to keep accurate orientation of the paper.
- Double papers, deflective paper, empty paper light control system to ensure reliable delivery and reducing waste.
- The modular design of electrical control, adopt imported electric elements to ensure accurate control.
- Touching screen shows running state and dynamic monitoring. It’s easy to do adjustment of the machine and fault clearance.
- Oil supply system with circulation cooling and oil less alarm to ensure all running parts have good lubrication and long durability.
|
Model |
AEM-1080Q |
|
Max. paper size |
1080x780mm |
|
Min. paper size |
400x330mm |
|
Max. cutting size |
1075x770mm |
|
Die frame inner size |
1100x790mm |
|
Cutting plate size |
1080x780mm |
|
Min gripper edge size |
7mm |
|
Cutting precision |
? ± 0.1mm |
|
Max. cutting pressure |
300T |
|
Max. cutting speed |
7000S/H |
|
Pre-stacking height |
1550mm |
|
Delivery stack height |
1400mm |
|
Application |
White board 0.1~2mm |
|
Corrugated paper < 4mm> |
|
|
Main motor power |
11KW |
|
Total power |
17.8KW |
|
Machine dimension [L(+pre-stacking)xW(+platform)xH] |
AEM-1080 : 4880(+1650)x2100(+1600)x2350mm |
|
AEM-1080Q : 5880(+1650)x2100(+1600)x2350mm |
|
|
AEM-1080 weight |
14T |
|
AEM-1080Q weight |
16T |
