BZ-LB5E
BZ-LB5E Automatic Middle Speed Paper Cup Machine
This machine adopts open cylinder indexing slot wheel, The machine through only one aluminum plate to complete the process of making cups, it’s single shaft & plate system, then make the machine smaller and faster, It has automatic lubricating oil system, photoelectric detection, fault alarm, counting, cam system, touch screen and other functions, Through the automatic feeding, cup-fan-wall sealing, oiling, bottom punching, heating, knurling, curling, discharge cup etc. continuous process. can improve the production of beverage mugs, tea mugs, coffee cup, advertising cup, ice cream cups speed is the ideal equipment.
|
Technical Specifications |
|
|
Model |
BZ-LB5E |
|
Paper Cup Size |
3oz-9oz and 9oz-16 (mold exchangeable) |
|
Raw Material |
One-side PE (polyethylene) film coated / laminated paper |
|
Suitable paper weight |
160-350 gsm |
|
Productivity |
90-105 pcs/minute |
|
Power Source |
220V/380V 50Hz or other required |
|
Total Power |
6KW |
|
Total Weight |
2500KGS |
|
Package Size (L x W x H) |
2350x1100x2000mm |
|
Working Air Source |
0.4 Mpa, Air Out-put:0.6 m3/minute |
|
Operator |
one person |
|
Working hours |
24 hours |
