CQK-A3 Automatic Strapping Machine

CQK-A3 automatic strapping machine is a paper using tape or OPP transparent tape strapping machine, the use of hot melt bonding process, touch screen interface design and operation is simple and convenient especially suitable for light goods packaging, suitable for pharmaceutical, food, printing, finance, IT, daily chemical industry and other industries. Can be on the paper box conjoined bundling, but also for many pieces, many, many roots, many boxes of small hard and soft products to implement group bundling. OPTIONAL: TAPE RACK ATTACHMENT This attachment is used for making the machine more efficient with longer tape (500m length tape), thus lowering the frequency of tape changing.

Features:

Use touch screen interface design, easy to operate, especially suitable for the packaging of light goods, use paper tape or transparent tape, use hot melt adhesive, beautiful and generous product.

Product Application:

This machine is suitable for pharmaceutical, food, printing, finance, IT, daily chemical and other industries. Can be divided into single bundle, double bundle, three bundles, well glyphs and soft goods abnormity bales. High quality low cost: bundle moderately, adhesive, each bundle package cost takes only about 5 cents. Energy saving material, low power consumption, packaging material province. For heat-sensitive drugs (suppositories, injection, biological agents) bales more appropriate available ordinary paper tape, film, also can use color, anti-counterfeiting, anti-static belt.(note: in addition to paper tape and film tape, other types of tape shall be provided according to customer's requirements.)

Function:

The whole stack of products before packaging (can also be used as final packaging) is tightly fixed to ensure smooth appearance, no friction, no scattering and no deformation of products, which is conducive to packaging, transportation and packing. Function: the whole stack of products before packaging (can also be used as final packaging) is tightly fixed to ensure smooth appearance, no friction, no scattering and no deformation of products, which is conducive to packaging, transportation and packing.



Technical Specifications

Model

CQK-A3

Power Supply

220V/50Hz

Strapping tape

OPP

Control system

PLC

Coil size

Inner diameter: Φ40mm ; Outer diameter: Φ180mm                Thickness: 0.12mm ; Coil width: 30mm/20mm

Shelf size

Inner diameter:  W360*H160mm

Packing range

Max: W360*H160mm?Min: W30*H10mm

Packing speed

20~26pcs/min

power

80W

Bonding mode

Hot melt

Tighten force

5-99N (adjustable)

Machine size

L560*W380*H500 (mm)

Machine weight

40Kg
