BCM-200
BCM-200 High Speed Paper Cup Machine
BCM-200 High Speed Paper Cup Machine
Features:
- High speed
- Energy conservation
- Environmental protection
- Brain power
- Stabilization
|
Technical Specifications |
|||
|
Model |
BCM-200H |
BCM-200M |
BCM-200S |
|
Weight |
3.3T |
3.3T |
2.6T |
|
Packing size (LxWxH) |
2800x1400x1900mm |
2700x1400x1900mm |
2300x1400x1900mm |
|
Electrical specification |
3 Phase 380V, 15KW |
3 Phase 380V, 15KW |
3 Phase 380V, 18KW |
|
Air consumption |
0.5-0.7MPa, 0.5m³/min |
0.5-0.8MPa, 0.5m³/min |
0.5-0.7MPa, 0.5m³/min |
|
Max. output |
150pcs/min |
160pcs/min |
180pcs/min |
|
Suction system |
Oblique suction |
Oblique suction |
Oblique suction |
|
Raw material |
Single PE / double PE |
Single PE / double PE |
Single PE / double PE |
|
Grammage of paper |
150-380g/m² |
150-380g/m² |
150-380g/m² |
|
Paper cup Specification
|
A ? 60-95mm B ? 45-75mm C 135-170mm D 5-12mm |
A ? 60-95mm B ? 45-75mm C 40-135mm D 5-12mm |
A ? 50-80mm B ? 35-58mm C 40-95mm D 5-7mm |
