KYD-750
KYD-750 Semi-Auto Hang Tags Stripping Machine
KYD-750 Semi-Auto Hang Tags Stripping Machine
Features:
- KYD-750 Semi-auto Hang Tags stripping machine is suitable for removing clothing tags, cards, small medicine boxes, cigarette boxes, toy boxes and other cardboard boxes.
- Not need the mould for different product sizes, with the upper pressing plates & lower pins to adapt to different products size & shape.
- The main action is driven by the servo motor, liner screw and hydraulic system, which makes the equipment more accurate and convenient to use, with low failure rate and agile action.
- Save Labor and Save tool cost and mould cost, high efficiency, simple operation, increasing user’s production capacity
|
Technical Specifications |
|
|
Model |
KYD-750 |
|
Max Material Stack Size |
750*720MM |
|
Max. Material Stack Height |
80MM |
|
Mini Material Stack Height |
40MM |
|
Max. Products Size |
740*200MM |
|
Mini. Products Size |
40*31MM |
|
Max Pressure |
40kn |
|
Speed |
8 times/min |
|
Total Power |
5KW |
|
Average Power |
3.5KW |
|
Air Consumption |
2L/min |
|
Compressed Air |
5-6 Bar |
