OYANG-16S

OYANG-16S Non-Woven Box Bag Making Machine

Leader Non-Woven Box Bag Machine is a world first set 3D one time forming machine, which start to developed since 2009 and successfully coming at October 2013 year, YouTube and Facebook have all records! Till now, it has obtained 12 invention patents and more than 30+ new-use patents. More than 1000+ customers have been using our equipment in China domestic market, and exported to more than 120+ countries, accounting for more than 90% of the market sales share of this equipment. This machine is designed for peritoneal non-woven fabric and pure non-woven fabric molding, can replace the traditional sewing more than 200 people, rapid mold changes 20 minutes, the equipment operation is efficient, stable, mass used in takeout, tea, wine, beverage, clothing footwear, gift advertising packaging! Advantage: The servo motor adopts 630 type, portable handle automatic centering, automatic deviation correction at the bag mouth, intermittent automatic adhesive tape pasting, and electric punch. Daily output of 90,000-100,000 pcs laminated cooling box bag!!

Technical Specifications

Model

OYANG-16S

Roller width

520-1160mm

Bag making speed

40-80pcs/min

Bag Width

100-500mm

Bag Height

220-450mm

Gusset

80-220mm

Power supply

380V

Total power

55KW

Rated power

18KW

Overall size

L 11000* W 6500* H 2650mm

Weight of Machine

10000KGS (40HQ*1 + 1*20GP)

Handle Length

380-600mm

Handle Width

25mm/30mm
