OYANG-17

OYANG-17 Automatic Non-Woven Box Bag Making Machine with Online Handle Attach with Cooling Box Bag Function

OYANG-17 Automatic Non-Woven Box Bag Making Machine with  Online Handle Attach with Cooling Box Bag Function

Latest features:

  1. Bag mouth auto adjustment
  2. Handle auto center adjustment
  3. Handle length auto change
  4. Speed 80-90pcs/min (parts high precision)
  5. Mould change time reduce to 30-50mins
  6. Servo Motor-28PCS
  7. Increase speed from 50 pcs/min to 90pcs/min, wastage 0
  8. Tape running according to each bag size, wastage 0%

Technical Specifications

Model

OYANG-17

Roller width

560-1160mm

Bag making speed

80-90pcs/min

Bag width

100-500mm

Bag Height

180-450mm

Gusset

80-220mm

Power supply

380V

Total power

55KW

Rated power

20KW

Overall size

L 11000* W 4800* H 3100mm

Weight of Machine

12500KGS (40HQ*1+20FT*1)

Handle Length

370-550mm

Handle Width

25mm &30mm

PP woven thickness

80-140gsm

Non-woven thickness

80-140gsm
