HT-1250

HT-1250 Sheet-feeding Bag Tube Forming Machine

This machine is a professional tube forming machine with automatic sheet-feeding, top folding (insert pasting), tube forming, gusset forming, and hot melt glue system as standard device. All the paper on the machine needs die-cutting in advance, applicable paper above 150g/m². This machine is easy to set up and operation, which bring efficiency during production, is very suitable for the production of multi-species and small paper bags. If you want to use the machine to replace manual tube forming, improve the production environment, reduce production cost, and improve the quality of paper bags, this machine is an ideal choice. Suitable Paper: Art paper, white cardboard paper, kraft paper or grey cardboard paper, all paper need die cut in advance.

Technical Specifications

Model

HT-1250

Max. sheet (LxW)

1250x600mm

Min. sheet (LxW)

520x320mm

Sheet weight

150-300g/m²

Bag width

180-410mm

Bottom width

70-175mm

Bag tube length

250-570mm

Speed

50-100bags/min

Top folding depth

30-70mm

Total / production power

15/9kw

Voltage

380V

Machine size (LxWxH)

12600x2500x1800mm

Total weight

5.8T

Glue type

Water base glue and hot-melt glue
