GPL-5575C+GPS-7040PE
GPL-5575C+GPS-7040PE Automatic Side Sealing and Shrinking Machine (without conveyor)
GPL-5575C automatic medium speed side sealer machine with the function of automatic film feeding punching, coating, sealing cutting, waste film automatically rolling in one time which is widely used in mass production packaging line.
|
Technical Specifications |
||
|
Model |
GPL-5575C |
GPS-7040 |
|
Machine dimension |
L2320×W1650×H1430mm |
L3300×W1000×H1710mm |
|
Packing size |
L≥120, H<230, W>90mm, W+H<680mm |
L2200×W550×H300mm |
|
Cutter size/ tunnel size |
L750mm |
L2400×W700×H400mm |
|
Max Packing speed |
0-10pack per minute (depends on product size) |
0-20Pcs/min (depends on product size) |
|
Product size |
Pizza Box: 810 x 450 x 110mm |
Pizza Box: 810 x 450 x 110mm |
|
Net weight |
700kg |
850kg |
|
Power |
3KW |
22KW |
|
Power supply |
380V 50/ 60Hz, 3 Phase |
3?, 220/380V, 50/ 60Hz |
|
Air pressure |
5.5kg/cm³ |
/ |
|
Max current |
10A |
35A |
|
Film material |
PE film |
PE film |
|
Table height |
850+30mm |
850+30mm |
|
Product feed direction |
right to left |
right to left |
