HR1100I

Semi Automatic Paper Bag Tube Forming Machine

This machine is first part of paper bag making machine. It produce paper bag tube with top creasing as well as bottom creasing for 90?200gsm paper.

Bag making process: Paper feeding—> paper top creasing—> paper folding & bag tube forming —> bag bottom creasing—> product output


Technical Spesification
Model      HR-1000I
Paper Weight      90-350 gsm
Paper Width      450-1050 mm
Paper Length      180-500 mm
Bag Width      150-400 mm
Bag Length      180-500 mm
Bag Bottom Width      50-180 mm
Speed      60-90 pcs/min
Glue Type      Hot?melt glue (Water?soluble cold glue is also ok)
Suitable Paper Type      Kraft paper, Art paper, White cardboard, Laminated paper
Total Power      5.5 kw 380 V
Machine Weight      5.5 T
Machine dimension      8000x1600x1600
