JB-8012G-6090G
Microcomputer Screen Printing Machine
JB-8012G-6090G Microcomputer Screen Printing Machine. The height of screen-release device can be quickly adjusted, ensure printing precision and quality.
- The printing effect is very excellent by using four air cylinders.
- The height of screen-release device can be quickly adjusted, ensure printing precision and quality.
- The tension pressure for printing blade, ink-return blade is adjusted separately at infinite speed, which increases the service lift and printing quality of half tone.
- Printing stroke and half tone fixed system can be quickly adjusted to meet different printing area.
| Technical Specification | ||
|---|---|---|
| Model | JB-6090G | JB-8012G |
| Max. printing acreage | 600x900 mm | 800x1200 mm |
| Max. dimension of the frame | 950x1100 mm | 1250x1500 mm |
| Dimension of the workbench | 800x1000 mm | 1000x1300 mm |
| Printing speed | 1200 pcs/h | 1000 pcs/h |
| Printing to thickness | ~25 mm | ~25 mm |
| Height of instant off-network | 0-15 mm | 0-20 mm |
| Weight (about) | 600 kg | 900 kg |
| Overall dimensions | 1600x1200x1300 mm | 1900x1400x1400 mm |
| 3P 380 V 50 Hz | ||
| Printing motor | 0.75 KW | 1.1 KW |
| Printing shaft | 0.75 KW | 1.1 KW |
| Wind machine | 1.1 KW | 1.5 KW |
| Power | 2.6 KW | 3.7 KW |
