RY-320-480-5D
Flexo Printing Machine
RY-320-480-5D Flexo Printing Machine. Unwinding, web guiding, printing, IR drying, varnishing (UV), laminating, rotary die cutting, discharging the waste and rewinding can be finished in me process. This is an ideal machine for printing factories to print many kinds of labels.
- Adopt the anilox roller to spread ink
- Unwinding and rewinding are controlled by magnetic power brake, clutch, (or by automatic tension controller of mitsubishi, made in Japan).
- Each printing unit adopt 360° for registration
- Each printing unit have one IR drier
- The rubber roller can break away automatically while parking, and running at a low speed, in order to avoid ink being dry
- The main motor is adopted the import stepless regulation of frequency coversion
- Unwinding, web guiding, printing, IR drying, varnishing (UV), laminating, rotary die cutting, discharging the waste and rewinding can be finished in me process. This is an ideal machine for printing factories to print many kinds of labels
| Technical Spesification | ||
|---|---|---|
| Model | RY-320-5D | RY-480-5D |
| Printing speed | 5-60m/min | 5-60m/min |
| Printing color | 5 colors | 5 colors |
| Max web width | 320mm | 480mm |
| Max printing width | 310mm | 450mm |
| Max rewinding diameter | 550mm | 750mm |
| Printing girth | 175-380 mm | 180-580 mm |
| Precision of cromatography | +/-0.10 mm | +/- 0.10 mm |
| Dimension | 2100x1100x2600 mm | 2300x1260xx2700 mm |
| Machine weight | 2600 Kg | 3500 Kg |
