SGUV-1000B-1200B
UV Whole Coating Machine
The machine adopts international advanced coating technology and combines the features of the national industry. It is a kind UV oil-passing and glazing equipment for paper structure. After being treated by the machine, printed surface will have a higher glossiness with function of antifouling, damp-proof, lade-proof and water-proof. Especially, adopting the PLC air knife system to ensure the paper over 80g/m2 coating easily. It is ideal equipment for the process to promote the glazing quality of printer matter and create high profit.
| Technical Spesification | ||
|---|---|---|
| Model | SGUV-1000B | SGUV-1200B |
| Max coating width | 950 mm | 1150 mm |
| Paper tickness |
80-157 g/m2 (white air knife) 157-600 g/m2 |
80-157 g/m2 (white air knife) 157-600 g/m2 |
| Max coating speed | 60 m/min | 60 m/min |
| Power | 65 Kw | 65 Kw |
| Weight | 3000 Kg | 3500Kg |
| Overall dimension | 9100x1600x1610 | 9100x1600x1610 |
