ZXH-A1200
ZXH-A1200 Non Woven Single Color Screen Printing Machine
ZXH-A1200 Non Woven Single Color Screen Printing Machine. Printing speed 500-1400m/hour. Max printing size 1150x1400mm.
Features:
- Automatic feeding, printing, drying and collecting, saving labor and overcome the constraints of weather conditions.
- Pressure equalization and thick ink layer, adapt to the printing of high-grade non woven products.
- Various size of screen frame plate is available.
- Multiple patterns can be printed simultaneously when do large format printing which is largely improved the work efficiency.
- Minimum effective pattern printing gap low to 10mm before and after full-ptter printing, largely reduce the material consumption.
- The driving of the whole machine and chromatography system adopts servo motor control, ensure the printing precision.
- Printing position is accurate and stable. It can be used together with transverse cutting, slitting and non woven bag making machine, which is largely improved production efficiency.
|
Technical Specifications |
|
|
Model |
ZXH-A1200 |
|
Material unwinding width |
1200mm |
|
Max diameter of material roll |
1000mm |
|
Max printing size |
1150x1400mm |
|
Material basis weight |
45-158g/m² |
|
Printing speed |
500-1400m/hour |
|
Total power |
28KW/380V |
|
Dimension |
7500x1800x2200mm |
|
Weight |
3000kg |
