DB-470B

DB-470 series automatic thermoforming machine, as the first domestic new-type machine, is researched and developed by our scientific researcher according to the market demands and our past production technology. This machine is a multi-station automatic machine, which solve the problems of food packaging hygienic standards. It not only solves a lot of problems effectively in the production of PP, PS, PET, PVC and PLA plastic products, such as large capital investment, large labor input, complicated production process, lower hygienic security, etc., but also has extensive usage. It can be used in the production of PP, PS, PET, PVC, PLA plastic products using in metals, food, pharmaceutical, etc.  The machine enjoys beautiful appearance and good price. It is popular with the customers at home and abroad!

Technical Specifications
Name	DB-470B
Max. Cutting Speed	10-35 times/min
Max. Forming Length	260mm
Max. Forming Width	470mm
Max. Forming Depth	70mm
Available Material	PP/PS/PET/PVC/PLA
Material Thickness	0.1mm-1.5mm
Heating Power	22KW
Motor Power	10KW
Power and Total Power	380V 50HZ?220V 60HZ? Three-phase and four-wire
Pressure of Water Supply	0.2MPa
Water Consumption	0.3m3/h (Tap water or Circulating cooling water)
Exhaust Volume	≥0.6m3/min
Air Pressure	0.6-0.8MPa
Machine Install Size	5000×1600×2100mm
Packing Size	5200×1800×2300mm
Max. Width of Material	510mm
Weight	4000KG
