HSB300
HSB300 Hydraulic Plane Cutting Machine
HSB300 Hydraulic Plane Cutting Machine
Features:
- The machine is installed with central oil supply lubrication and collecting, reflowing and filtering system, which can fully lubricate the main shaft and prolong the service life of machine.
- Large area of pressing board of cutting makes it possible to cut large-sized materials.
- Operation with both hands, safe and reliable.
- The cutting dept of cutter is simple to set and the cutting is accurate.
- The height of return travel of pressing board can be set freely, which reduces unnecessary idle travel.
- Products of special specifications can be customized.
|
Technical Specifications |
|
|
Model |
HSB300 |
|
Max. cutting force |
300KN |
|
Tension distance |
50-150 |
|
Cutting area |
1600x500 |
|
Stroke adjusting range |
5-100 |
|
Motor power |
2.2kw |
|
Weight (approx.) |
1800kg |
