FQJ-2100
Microcomputer High-speed Paper Slitting Machine (Vertical)
This machine is suitable for slitting and trimming the super-sized coiled material like plastic films, i.e. paper, cloth, and all kinds of paper-plastic compound materials like laminated paper, coating paper, synthetic leathers, synthetic leathers, and so on for printing and packing.
| Technical Spesification | |
|---|---|
| Model | FQJ-2100 |
| Rang of gram weight | 50-400g |
| Cutting width | 50-1900mm |
| Max cutting diameter | 1300mm |
| Finished spesification width | 50/200mm |
| max diameter of paper | 1100mm |
| Deviation of cutting width | +/- 0.5 mm |
| Speed | 0-150m/min |
| Suitable material | 50-400g |
| Rang of rewinding | 50-1900mm |
| Feeding tension control | 40kg magnetic powder control |
| Power | 5.5kw |
| Dynamic balance | 100mm |
| Max diameter of rewinding | 1100 mm |
| weight | 6000KGS |
| Overall dimension | 4100x3400x2100 mm |
