MHC-1060
MHC-1060 Automatic Die Cutting & Creasing Machinery
MHC-1060 Automatic Die Cutting & Creasing Machinery. Stock range Paper: from 90 to 2000g/m2, 0.1~2mm, corrugated board: up to 4mm. Max.working speed 7500s/h.
|
Technical Specifications |
|
|
Model |
MHC-1060 |
|
Max. sheet size |
1060x760mm |
|
Min. sheet size |
400x350mm |
|
Max. cutting size |
1050x750mm |
|
Min. gripper margin |
9-17mm |
|
Inner chase size |
1100x790mm |
|
Stock range |
Paper: from 90 to 2000g/m2, 0.1~2mm, corrugated board: up to 4mm |
|
Die cutting accuracy |
≤±0.1mm |
|
Max.die cutting force |
300T |
|
Max.working speed |
7500s/h |
|
Max. feeder pile height |
1600mm (with wooden pallet) |
|
Max. delivery pile height |
1400mm (with wooden pallet) |
|
Dimensions (LxWxH) |
6286x4257x2367mm (L: paper prepared track included, W: platform included) |
|
Net weight of machine |
16T |
|
Main motor wattage |
11kw |
|
Full load wattage |
16.9kw |
|
Air requirement |
Pressure:0.6~0.7Mpa, Flow:≥0.37m3/min (prepared by user) |
