TM-440

Envelope Window Filming Machine

Air suction bottom paper extraction separates papers reliably, and can be fed with paper continuously. Forcibly positioning and automatic wheel rolling gumming ensures the even glue amount. Film is adjusted by CVT, which is convenient and reliable.Air suction bottom paper extraction separates papers reliably, and can be fed with paper continuously. Forcibly positioning and automatic wheel rolling gumming ensures the even glue amount. Film is adjusted by CVT, which is convenient and reliable.

Techincal Specification
Max. operating speed 12000 pcs/h
Range of processed products 110x175mm - 450x600mm
Applied paper 80-220 g/m2
Electricity capacity 3.7 kw
Window specifications 60x80 - 300x300 mm
Machine weight 1800kg
Machine diimension (LxWxH) 3200x1050x1550 mm
