ZF-330

Envelope & Paper Bag Pasting Machine

ZF-330 envelope machine has both Chinese and Western usages. Paper feed parts employ the structure of bottom air-suction paper extraction, while air-suction transport avoids double-feed phenomena. Automatic four-edge indentation increases precision and reduces errors. Horizontal fold-parts use roller air suction. Paper jam decreases and paper bags can go through the fence smoothly. Traditional system employs bearing, synchronous wheel and timing belt to cut the noise.

Technical Specification
Model ZF-330
Max. working velocity 12000 pcs/h
Processing spec Chinese envelope: 100x100mm - 160x260mm
Western envelope: 90x100mm - 230x160mm
Applicable paper 80-157 g/m2
Motor power 4.5 kw
Machine weight 1500 kg
Machine dimension (LxWxH) 3000x850x1450 mm
