XF-6090C-80120C
High Precision Screen Printing Machine
Mesin sablon multi fungsi. Dengan menggunakan mesin ini, hasil dan kualitas sablon lebih stabil dan konsisten. Bisa digunakan untuk spot UV jika digabung dengan mesin curing XFUV/JB SERIES.
- Oblique arm structure
- The platform with distributed evenly air suction, automatic vacuum absorbing
- Printing/ink withdrawing speed are controlled and adjusted respectively
- High precision four cylinder device ensures printing/ink withdrawing pressure stable
- Ink scratching angle is adjustable
- Double push rod deceleration apparatus that drives print cross bar are make in Taiwan
- The printing processing works together with the imported reducer, so the printing is smoother than before. Print travel is controlled by sensor switch.
| Technical Specification | ||
|---|---|---|
| Model | XF-6090C | XF-80120C |
| Max. printing dimension | 600x900mm | 800x1200mm |
| Dimension of the workbench (outside) | 800x1000mm | 1000x1300mm |
| Max. printing speed | 600-1300pcs/h | 400-1200pcs/h |
| Overall dimension | 1450x1800x1300mm | 1700x2000x1350mm |
| Voltage power | 380v50Hz3.5kw | 380v50Hz3.5kw |
| Max. Dimenision of the frame | 1000x1200mm | 1300x1500mm |
| N.W | 500kg | 600kg |
| Machine dimension | 1800x1100x1140mm | 2100x1400x1140mm |
