XF-PS4060-6090
Screen Process Press Machine
Be applied to the flat printing for glass, CD, nameplate, stickers, credit card, ceramic colored paper, wooden toy puzzles, PCB, SMT tin ointment, and membrane switches in electronic industry. It is also applicable to the flat printing such as golden and silver cardboard, metal sheet, and other products with the material of
- vertical structure with the motor driven printing plate goes up and down vertically, and the motor driven print head moves left/right.
- Single chip controlled circuit, printing and plate goes up and down using independent driving source.
- Pneumatic controller controls the printing knife moves up and down, photocell eye controls the stroke, which is independent to tune.
- Set manual/semi-automatic/automatic three modes, the break time of printing is digital controlled.
- Independent deigned head rising and down setting, makes it convenient to clean the scraping blade/reclaiming blade, screen plate during loading and unloading.
- Double guide column master the clamps arm and install the adjusting device to adjust the distance between plates at the same time, which is convenient to tune.
| Technical Specifications | ||
|---|---|---|
| Model | XF-PS4060 | XF-PS6090 |
| Max. Print Size | 400 x 600mm | 600 x 900mm |
| Max. Frame Size | 700 x 1000mm | 900 x 1300mm |
| Work Platform Size | 500 x 800mm | 700 x 1100mm |
| Material Thickness | ~40mnm | ~40mm |
| Off-network | 0 N 20mm | 0 N 20mm |
| Print Speed | 900pcs/h | 800pcs/h |
| Weight(Kg) | 650kg | 850kg |
| Overall Dimension | 1160 x 870 x 1750 | 1460 x 1070 x 1750 |
| Print Motor | 0.2Kw | 0.2Kw |
| Print Shaft | 1.5Kw | 2.2Kw |
| Air Motor | 0.55Kw | 0.75Kw |
| Total Power | 2.25Kw | 3.15Kw |
